What Is a DIN 261 T-Head Bolt
A DIN 261 T-head bolt — also called a hammer head bolt or T-slot bolt — is built to solve a specific clamping problem: securing a workpiece, vice, fixture, or die set directly onto the T-slots machined into a milling table, drill press bed, or press bolster, without needing a threaded hole in the table itself. The rectangular “T” head slides into the slot and rotates a quarter-turn to lock under the slot’s overhang, taking the clamping load in shear against the slot walls rather than relying on the head bearing on a flat surface.
Getting the head width and height right against your specific T-slot size (per DIN 650) matters more than with a standard hex bolt — too loose a fit and the bolt rocks under load; too tight and it won’t seat into the slot at all. That’s exactly why a size-by-size dimension and weight reference is useful before ordering, rather than assuming one “M12 T-bolt” fits every M12-rated slot.
Akbar Fasteners Pvt. Ltd. manufactures DIN 261 T-head bolts in-house at our Mumbai facility, under ISO 9001:2015, with full mill test documentation, and exports this range to over 50 countries.
Where DIN 261 Bolts Genuinely Earn Their Place
Purpose-Built for T-Slot Tables
The rectangular head is sized to slide and lock inside standard T-slots, distributing clamping load across the slot walls rather than a single flat bearing point.
Consistent Dimensional Tolerance
Head width, height, and shank dimensions held to DIN 261 tolerance so the same size bolt fits reliably across different tables rated to the same slot standard.
Full Size & Weight Reference
A published dimension and weight chart lets you plan freight, packaging, and slot compatibility before placing an order — not after the bolts arrive.
Multiple Material & Grade Options
Mild steel and stainless steel available across common property classes, matched to fixturing load and workshop environment.
DIN 261 T-Head Bolt Dimension & Weight Chart
Standard nominal dimensions and approximate weight by thread size — head width (b) and head height (k) are the two figures to check first against your table’s T-slot size (per DIN 650) before ordering. Weight is given per piece at a 50mm reference shank length; actual weight scales with the ordered length and should be recalculated for your final bill of materials.
| Thread Size (d) | Head Width (b) | Head Height (k) | Head Length (e) | Recommended T-Slot | Approx Weight/pc @ L=50mm |
|---|---|---|---|---|---|
| M6 | 13 mm | 6 mm | 16 mm | 8 mm | ~0.014 kg |
| M8 | 16 mm | 7 mm | 20 mm | 10 mm | ~0.024 kg |
| M10 | 18 mm | 8 mm | 22 mm | 12 mm | ~0.038 kg |
| M12 | 22 mm | 10 mm | 28 mm | 14 mm | ~0.062 kg |
| M16 | 28 mm | 12 mm | 34 mm | 18 mm | ~0.115 kg |
| M20 | 34 mm | 14 mm | 40 mm | 22 mm | ~0.195 kg |
| M24 | 40 mm | 16 mm | 48 mm | 28 mm | ~0.305 kg |
| M30 | 48 mm | 19 mm | 56 mm | 36 mm | ~0.520 kg |
| M36 | 56 mm | 22 mm | 64 mm | 42 mm | ~0.790 kg |
Figures shown are representative reference values in steel for quick planning purposes and may vary slightly by manufacturer tolerance and shank length ordered. Please confirm exact dimensions against the current DIN 261 standard document or your engineering drawing, and request our certified dimensional data sheet, before finalizing a purchase order.
T-Slot Fixturing Fastener Range
T-Head / Hammer Head Bolts
Standard T-slot clamping bolts in mild steel and stainless, M6 to M36, custom length to drawing.
DIN 508 / 787T-Slot Nuts
Rectangular clamping nuts sized to match standard T-slot widths for fixture and tooling assembly.
Clamping KitsStep Blocks & Clamps
Adjustable step blocks and clamp plates supplied as complete workholding sets for milling and fixturing.
Support HardwareStuds, Washers & Spacers
Matching studs, hardened washers, and spacers to complete a full clamping assembly to your specification.
DIN 261 Technical Overview
Available Materials
- Mild / Carbon Steel Standard Offering
- Stainless Steel 304 / 316 on Request
- Alloy Steel Higher Load Applications
- Surface Finish Black Oxide / Zinc Plated
- Custom Material To Specification
Mechanical Grades
- Property Class 4.6 General Fixturing
- Property Class 8.8 Higher Clamping Load
- Stainless A2/A4 Corrosion Resistant
- Threading Metric Coarse (Standard)
- Testing MTC / NABL on Request
Available Dimensions
- Thread Diameter M6 – M36
- Shank Length Custom to Drawing
- Head Style Standard T-Head Only
- T-Slot Reference Per DIN 650
- Packaging Loose / Boxed / Palletized
Application Areas
Wherever a workpiece or tool needs to be clamped directly to a T-slot surface.
Machine Tool Fixturing
table workholding
Press Tooling & Die Sets
for stamping presses
Jigs & Fixtures
fixture assembly
CNC Vice & Clamp Mounting
clamping systems to tables
Foundry & Pattern Shop
fixture clamping
Packaging Machinery
clamped to base frames
Metrology & Inspection Tables
gauging & inspection setups
Assembly Line Tooling
for line changeovers
Standard Export Documentation
Prepared as standard practice for every T-head bolt shipment.
Mill Test Certificate (MTC)
Material composition and mechanical property verification for every production batch.
Certificate of Conformance
Confirms the shipment matches the purchase order specification, size, and grade in full.
Certificate of Origin (COO)
Confirms India as country of manufacture for destination customs purposes.
Commercial Invoice & Packing List
Itemized value, Incoterm, and detailed carton/weight breakdown for customs clearance.
Dimensional Data Sheet
Certified head width, height, and length data against DIN 261 available on request before order confirmation.
Bill of Lading
Ocean or air freight shipping document confirming carrier, mode, and consignee details.
Internationally Recognised Standards Coverage
Related Fastener Grades & Materials
Hastelloy B-3 Stud Bolts
Nickel-molybdenum alloy fastening for reducing acid and severe chemical processing service.
View Hastelloy B-3 →Stainless Steel 316 Fasteners
Corrosion-resistant option for T-head bolts and general fastening in washdown or humid environments.
View SS 316 →Titanium Grade 5 Fasteners
Lightweight, high-strength alternative for weight-critical fixturing and tooling assemblies.
View Titanium Grade 5 →Top Nickel Fasteners Manufacturer
See our full in-house nickel alloy manufacturing and documentation capability.
View Manufacturer Page →Send Us Your
T-Slot Size & Load Requirement
Tell us your T-slot width, material preference, and quantity — we’ll confirm the correct DIN 261 size and issue a certified dimensional data sheet with your quote. Akbar Fasteners Pvt. Ltd. responds within 24 hours.
